Power Amplifier
Number of Powered Channels2
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)75 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)100 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)150 W
Discrete Power AmplifierYes
Amplifier TopologyClass A/B
Inputs Outputs
HDMI In / Out6 / 1
Analog In / Fixed Level Out3 in / out
Phono (MM) InYes
Digital In: Optical / Coaxial1 / 1
Multi-Room Out: analog / digital1 / 0
Multichannel Preamp Out2.2
Subwoofer Out2
Number of Speaker Terminals4
Speaker A / BYes
USB AudioUSB A (Host)
AM/FM TunerYes
Multichannel Surround Technologies
Max Number of Processing (Preamp) Channels2,1
HDMI
Total HDMI Inputs / No. Support 8K6 / 3
HDCP2.3 supportYes
HDMI Outputs: Main / Zone1 / 0
HDMI Upscaling1080P/4K to 8K
Audio Return ChannelARC
Video Dynamic RangeHDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
ALLM (Auto Low Latency Mode) Pass-through for gamingYes
Variable Refresh Rate / Quick Frame TransportYes / Yes
HDMI Pass-Through in Standby ModeYes
Performance Technologies
Pure Direct ModeYes
Gold Plated RCA TerminalsYes
Hyper Dynamic Amplifier Modules (HDAM)Yes
Music File Support
Lossy FormatsMP3 / WMA / AAC
Lossless formatsFLAC HD 192/24 / WAV 192/24 / ALAC 192/24
DSD Audio2.8 MHz / 5.6MHz
Gapless PlaybackFLAC, WAV ,ALAC ,DSD
Compressed Audio Enhancer: MDAX2Yes
Network Audio SharingYes
Streaming Services
HEOS Multi-room and StreamingYes
AirPlay Audio StreamingAirPlay2
Internet RadioTuneIn
Spotify*Spotify Connect
*availability of services might vary per regionOther Streaming Services *Amazon Music HD/Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / Soundcloud / Mood Mix
*availability of services might vary per regionRoon testedYes
PandoraYes
SiriusXMYes
Network Connectivity
Ethernet PortsYes
Bluetooth Re-transmit for Bluetooth headphonesYes (with volume control)
Wi-FiYes
BluetoothYes
Smart Home Integration and Control
Voice Assistant CompatibilityAlexa / Google Voice Assistant / Apple HomePod / JoshAi
App for Smart Phones & Tablets (iOS & Android)Marantz AVR App
HEOS Multi-Room IntegratedYes
HEOS Link Compatibility: IR/ IPYes / Yes
Multi-Room zones1
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog2 Ch / 2Ch / Yes / Yes
Zone Audio Output: Speaker / PreoutNo/Yes
HDMI DiagnosticsYes
Others
Front Displayport hole OLED
GUI LanguagesEnglish, Spanish, French
Setup AssistantYes
Smart Select on RemoteYes
Firmware Update by Network / USBYes / Yes
ECO ModeYes
Auto Power offYes
Sleep TimerYes
General
System Remote ControlRC-052SR
Power Consumption in W210
Standby Consumption in W0.2
CEC Standby Consumption in W0.5
Network Standby Consumption in WLess than 2.0
Maximum Dimensions【 w/o Antenna :(W x D x H) in inches 】:
【 17.4 x 14.7 x 4.3 】What's in the boxMain unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, 2 External Detachable Antenna, AC cord
UPC code747192140267
